Description
Multifunction rear light having three functions: direction indicator, brake light, position. The lamp has 12 LEDs 6 red ones and 6 orange ones. Suitable for installation in all types of vehicles as basic or optional equipment. Universal input voltage, compact size, modern design, low power consumption and high resistance to weather conditions is the reason why this light is often chosen by the customers.
Specification of cores:
White – Ground
Black – rear position light (0.2 / 0.4 W)
Red – brake light (1.6 / 3.4 W)
Yellow – rear direction indicator (1.9 / 1.9 W)
| Light group: | HOR 86 |
| LED quantity: | 12 |
| Light category: | Multifunction rear |
| Rear position light: | Yes |
| Supply voltage: | 12/24V |
| Operating temp range: | -30°C to +50°C |
| Cable: | 4×0.5mm², 1m length |
| Side: | Universal |
| Brake light: | Yes |
| Rear direction indicator: | Yes |
| LED light: | Yes |
| Ingress protection rating: | IP68 |
